Aja ROI-HDMI till SDI Scan Converter

ROI-HDMI till SDI Scan Converter tillåter konvertering med exceptionellt hög kvalitet från dator via HDMI till SDI. Den smidiga enheten är portabel och enkel att ta med.

Fördelar

• DVI to SDI conversion
• Region of Interest scaling
• DVI loop through
• DVI-to-HDMI adapter supported on input and loop through
• Audio embedding
• Aspect ratio conversion
• Genlock input
• Conversions are configured via included MiniConfig software
• Uses 5-18VDC power (universal power supply included)

Format

DVI:

• VGA (640 x 480) minimum
• WUXGA (1920 x 1200) 60 Hz max
• Frame rates are limited by the 165 MHz max rate of the DVI Rx

HDMI:

• 525i/625i
• 480p/580p (DSLR cameras)
• 720p 23.98/24/25/29.97/30/50/59.94/60
• 1080i 50/59.94
• 1080p 23.98/24/25/29.97/30
